Good Quality Laminated Glass Machine - Four Layers Glass Laminated Machine with EVA Film – Fangding
Good Quality Laminated Glass Machine - Four Layers Glass Laminated Machine with EVA Film – Fangding Detail:
Basic Info.
| Model NO. | FD-J-5-4 |
| Rade Power | 58kw |
| Outside Dimension(mm) | 2965*4600*2150 |
| Voltage | Customizable |
| Layer | 4 |
| Maximum Glass Thickness | 40mm |
| Vacuum Bag | 100% Improted Materials |
| Trademark | FANGDING |
| Specification | 2440*3660*4layers |
| HS Code | 84752919 |
| Processing Glass Size(mm) | 2440*3660*4layers |
| Floor Space(mm) | 4520*10500 |
| Warranty | 4300kgs |
| Color | Blue |
| Operation System | Siemens PLC |
| Installation and Commissioning | Technician to Your Factory for Free Installation |
| Transport Package | Plywood Packaging |
| Origin | Rizhao, China |
Four Layers Glass Laminated Machine with EVA Film
1.Product introduction
The heating room has been separated into independent champers by one flat cross wall.Each part has its own control system.Therefor you could laminated different kind of glass at the same time.
The vacuum pump and electrical elements are separated ,so that could reduce the damage to the electrical elements caused by the vibration of the vacuum pump.Improve the service life of those spare parts.
The cooling the faster the better the transparent.
There have three three layers try and three fans.It can seep up the glass cooling and improve the transparent.
You can set the cooling time,when the fan senses the position of the try,it will start working,until the set time stops.
Elevator lift platform,wireless remote control.
The Height of the platform to each layers has been designed and fully automated save time and labor.
Please feel free to contact me if you want more details.
Model
| Model | Processing glass size (mm) | Rated power | Operation system | N.W. | Outside dimonsion (mm) | Floor space (mm) | Production capacity (m2/cycle) |
| FD-J-2-4 | 2000*3000*4 layers | 38kw | Siemens PLC | 3700kgs | 2530*4000*2150 | 3720*9000 | 72 |
| FD-J-3-4 | 2200*3200*4 layers | 45kw | Siemens PLC | 3900kgs | 2730*4200*2150 | 4020*9500 | 84 |
| FD-J-4-4 | 2200*3660*4layers | 52kw | Siemens PLC | 4100kgs | 2730*4600*2150 | 4020*10500 | 96 |
| FD-J-5-4 | 2440*3660*4layers | 58kw | Siemens PLC | 4300kgs | 2965*4600*2150 | 4520*10500 | 107 |
Application
Building laminated glass,Stair handrail,Shower Room,Canopy,Ceiling,Silk laminated glass.Marble paper laminated glass,Smart glass,Color laminated glass and so on.
Shipping
Equipped with forklift, traveling crane professional equipment.
Specialized technicians are in charge of packing and fixing equipment, they are experienced.
Ensure the equipment is delivered to the customer’s factory safely!
2.Company introduction
Founded in 2003, the company is an enterprise integrating production, R & D, sales and service, covering an area of more than 20000 square meters.
Have built a number of modern production workshops and comprehensive laboratories.
The company is committed to providing glass deep processing enterprises with a full range of solutions for laminated glass technology.
Workshop
We make strict Quality testing before packing by professional staff and engineer.
The machine packed with standard package, will be fixed firmly in the container.
It makes sure the machine arrived our customers’ factory with good condition.
Honor
Our equipment is sold all over the world and has obtained various certifications. We have the strength and qualification to do what you need.
Exhibition
Fangding attend large exhibition both domestic and abroad every year!
We always make laminated glass in the glass fair, tempered laminated glass and bending laminated glass can be finished in one furnace.
Clients
We have clients from more than 68 countries.
Our products and after-sales service have been well received.
3.RFQ
1.What about the terms of payment?
Normally 30% prepayment, 70% before shipment by T/T
2.How many layers of machine do you have?
We have 2,3,4layers glass laminated machine,we also accept custom.
3.How about the after-sale service?
First of all, our equipment is guaranteed for one year
In addition, we have special after-sales customer service, 48 hours online service, ready to solve any problem for you
If you have any question,please feel free to contact me.
